10/04/2014
0.5 Nm ovoid 3.9 Watts 3.9 W Part number made to order
Torque rating of gearboxes : 0.5 Nm, high-performance plastic gears
Motors : nominal power 3 W, interference suppression for standard stocked products
Wide speed range : 0.3 to 430 rpm
Optional encoder built into the motor
Part numbers
www.crouzet.com
Type
Type
Voltage
Standard speed (rpm)
Output speed (rpm)
Ratios (i)
82861023
3.9 W
828610
24 V
4300
3,6
1200
Specifications
General characteristics
Motor
Gearbox
Maximum permitted torque from gearmotor under
continuous conditions for 1 million turns (Nm)
Axial load static (daN)
Radial load static (daN)
Max. output power (W)
Nominal output (W)
Gearbox case temperature rise (°C)
Weight (g)
Made to order products, available on request
Motors :
Other supply voltages
Motor with 2 ball bearings
Shaft lengths at front and/or rear
Lead outputs or radial tag terminals
Special interference suppression
Encoder : 5 pulses/rev
Gearboxes :
Special shaft
Ball bearing
Special greasing
Torque limiter F
Gearbox fixing M3
Other speeds
Dimensions (mm)
828610
828600
810210
0.5
1
8
3,9
3
50
160
N o
Legend
Unless otherwise specified, the characteristics given are applicable to all or part of the product range selected
